Quick Details

  • Place of Origin: Zhejiang, China (Mainland)
  • Brand Name: SANDI
  • Model Number: SDS-10KW
  • Output Power: 1 - 200KW
  • Output Type: single/3 phase
  • Size: 550*1300*700mm
  • Weight: 80kgs
  • Input Voltage: DC100~500V or DC200~820V
  • Output Voltage: AC 230V or 380V
  • Type: DC/AC Inverters
  • Output Frequency: 50/60HZ
  • Output Current: 15.15A
  • Control System: MPPT
  • Phases: single/3 phase
  • Current THD: At rated power and in the sine wave <3%
  • Anti-islanding: ≤0.5 sec
  • Max. Efficiency: 98%
  • Data Interfaces: External RS232C/RS485
  • Display: LCD
  • Certifications:: CE, VDE0126-1, AS4777, AS3100, G83/1, G59. ISO9001:2000

Packaging & Delivery

Packaging Details: Packing of 10kw grid tie solar system also called 10kw home solar power system with grid tie inverter is SANDI standard honeycomb carton packing.
Delivery Detail: 6-8 days



Product Description



Features:

1, Using IGBT module with stable performance and powerful protection function

2, Double CPU design, more safe and reliable

3, Double ways of MPPT input, higher conversion efficiency up to 98%

4, Color LCD touch screen display,easy to operation and set up parameters conveniently

5, Our grid tie inverters have passed CE, AS4777, AS3100, G83/1, G59/1 certifications approved by international standards

6, We have won great reputation for earnest service and compettive price all the time

7, Wide input voltage range

8, High reliability due to complete protection function

9, Powerful communication interfaces

10, Easy operation and installation

11, Easy-to-set multilingual LCD display

12, Adjustable protection/operation parameters



Specification:



Model

SDS-10KW

Isolation type

Transformer-less

DC Input

MPPT Voltage Range

DC100~550V



Max. DC Voltage

550VDC



Start Voltage

180V



Recommend PV Array

Open Circuit Voltage

200~400V



Control System

MPPT

 AC Output

Rated Output Power

10KW



Max. AC Output Current

45.2A

26.7A



Rated Grid voltage

AC230V

AC380V



Grid Voltage range

AC 185 ~ 264V

AC 342 ~ 418 V



Normal Grid Frequency

50/60Hz



Phases

1 phase 2 wire

3 phase 4 wire



Power Factor

>0.95



Current THD

At rated power and in the sine wave <3%



Control System

PWM



Anti-islanding

0.5 sec



Output Overload

100%



Max. Efficiency

98%



Euro Efficiency

97%





 Structure

Protection Class

IP20



Cooling system

Natural cooling



Power Consumption at Night

0W



Noise

<60dB



Data Interfaces

External RS232C/RS485



Display

LCD



Dimensions(W*H*D)

460*700*840mm



Weight

67.5kgs

70.5kgs



 Protection

Inverter

Input overvoltage, output short circuit, overheat, output DC component.



Grid

Anti-islanding, over/under voltage of grid, over/under frequency of grid.



 Environment

Environment

No corrosion gas, flammable gas, oil mist, dust etc.



Operation temperature

-10~40(55℃)



Stored temperature

-20~65



Relative humidity

0~100% (Do not wet with dew)

Warranty

3-years quality warranty

CE-Standards Complied

CE-Standards Complied: EN61000-6-2, EN61000-6-4(EMC), EN61558-1, EN61558-2-17,

EN50178, EN61000-1,

Certifications

CE, VDE0126-1, AS4777, AS3100, G83/1, G59. ISO9001:2000



Certifications



Packaging & Shipping

Welcome OEM service

MOQ=1 pc

Short delivery time

Can be custom made
