Quick Details

  • Place of Origin: China (Mainland)
  • Brand Name: SANDI
  • Model Number: SDS-75KW
  • Output Power: 1 - 200KW
  • Output Type: Triple
  • Size: 1000*800*2060mm
  • Weight: 800kg
  • Input Voltage: 200-820VDC
  • Output Voltage: 380VAC
  • Type: DC/AC Inverters
  • Output Frequency: 50/60HZ
  • Output Current: 113.63A
  • Method of Control: Max. Power Point Tracking Control (MPPT Control)
  • input: wide input range
  • Isolation: Transformer-less
  • THD: At rated power and the sine wave <3.5%
  • Efficiency: Above 95%
  • Over-load: Within 10 minute at 110% load
  • Outer Interface: RS 232C/RS485
  • Protective Function: Anti-islanding protection

Packaging & Delivery

Packaging Details Packing of 75kw 3 phase 380/220V 98% high efficiency solar grid tie inverter with CE,SAA,G83,G59,VDE AR N 4105 certifications is SANDI standard honeycomb carton packing with pallet. OR OEM
Delivery Time 12-15 days
Product Description


PV Grid-Connected Inverter

Summarize

The grid connected inverter can be used with a connection to grid or power lines. This type supplies the loading

appliances with electric power produced by photovoltaic systems.

The advantage of grid-type is not to worry any power wate, because by connecting inverter to grid, it can save any surplus electricity.



Features

*Wide DC input voltage range

*DSP controller

*High efficiency by using advanced IGBT and IPM

*MPPT(Maximum power point tracking) technology

*Transformer-less, High efficiency

*In accordance with international standards

*Quick and easy installation

*Operation parameters can be adjusted via LCD and keys

*The perfect protection function

*Designed to suitable for critical grid environment



Technical specification



Name of Type:

SDS-75KW

Isolation

Transformer-less

DC Input

Range of MPPT Voltage

200 ~ 820Vdc

(Run)Starting Voltage

400Vdc

Rated voltage

620Vdc

Method of Control

Max. Power Point Tracking Control (MPPT Control)

AC Output

Rated Output Power

75KW

Rated Voltage

Three phase 380V ±10% (Can adjust)

Frequency

Grid frequency 50Hz or 60Hz(can adjust)

Power Factor

0.95

THD

At rated power and the sine wave <3.5%

Efficiency

Above 95%

Over-load

Within 10 minute at 110% load

Prevention of Independent Operation

Within 0.5 Seconds

Structure

Cooling Method

Forced Air-cooling Type(AC Fan)

Protective Structure

IP 20

Noise of Equipment

Below 60 dB

Outer Dimension

(W×H×D)mm

1400x820x1550mm

Full Weight

300kg

Outer Interface

RS 232C/RS485

Protective Function

Inverter

Overvoltage of Input, Short of Output, Over-load, Protecting Inverter from Overheating, Short of Fuse, Preventing DC Output

Grid

Anti-islanding(IEEE 1547),over/under voltage of grid, over/under frequency of grid

Applicative Environment

Ambient Temperature

-20 ~ 40

Preserving Temperature

-20 ~ 40

Ambient Humidity

Relative humidity is below 90% RH(No Dewfall)

Altitude & Vibration

Below 1,000 m. Below 5.9m/sec²(=0.6g)

Ambient Temperature

Corrosive gas, flammable gas, oil mist and dust should not exist





Packaging & Shipping

Welcome OEM service

MOQ=1 pc

Short delivery time

Can be custom made
